Potentiometers - 3329 Single Turn DIP/RoHS
Terminal Resitance: ≤3%Or 3Ω
Contact Resistance Vartion: ≤3%Or 3Ω
Insulation Resistance: R1≥1GΩ
These principles today extra than ever form the basis of our success as an internationally active mid-size company for Single-stage EMI Filters, 3-Phase 4-Line EMI/RFI Filters, Trimming Potentiometers - Multiturn. Our company takes 'the prestige develops the market, the service creates the eternal' as the management idea, carefully selects and provides the high quality product for our customers. In case you are intrigued in any of our products or want to focus on a personalized get, please sense totally free to contact us. We take the modern quality management of 'new products, high quality, low prices, and excellent service' as our goal, and provide customers with high-quality and low-cost products and satisfactory services
Product Description
This kind of 3329 Trimming Potentiometer is mainly composed of a resistor body, a sliding arm, a sliding end, a rotating shaft, a rotating handle, a soldering piece, etc. It can be used alone in the circuit, or can be used together with other electronic components to form an electronic circuit with various functions. In addition, the 3329 Trimming Potentiometer has the advantages of high precision, good stability, small temperature coefficient, reliable contact, high temperature resistance and strong power load capacity. We also offer Potentiometer with different specification. It has a small size and is easy to stall and maintain. The 3329 Trimming Potentiometer can be widely used in induction cookers, humidifiers, air conditioners, range hoods, lighting, electric fans and other small appliance control panels. It is highly praised by our clients due to excellent performance.
Specification
| Range Of Nominal Resistance | 10Ω-2MΩ |
Resistance Tolerance | ±10% |
Terminal Resitance | ≤3%Or 3Ω |
Contact Resistance Vartion | ≤3%Or 3Ω |
Insulation Resistance | R1≥1GΩ |
Withstand Voltage | 101.2kpa 500v 8 5kpa 350v |
Effective Electrical Travel | ≥Total mechanical travel70% |
Rated Power | +70°C 0.5W； +125°C 0W |
Temperature Range | -55°C- + 125°C |
Tcr | ±250、±100ppm/°C |
5 Cycle | △ R≤±2%R, △(Uab/Uac)≤±5% |
Collision | 390m/s2. 4000times AR≤±3%R |
Vibration 10~500HZ,0.75mm Or 98m/S2, 6h | △R≤±1%R ，△（Uab/Uac) ≤±2% |
Climatic Order | △R≤±3%R, R1≥100MΩ |
7ctceiectrical Endurance | 0.5W、1000h、△R≤±3%R |
Mechanical Endurance | 200cycles、△R≤±3%R |
Steady Damp Heat | △R≤±3%R、R1≥100MΩ |
Total Mechanical Travel | 280° |
Staring Torque | <20mN.m |
Stopping Torque | >50mN.m |
Standard Package | 50pcs/tube |
We have many years of production and sales experience, we have accumulated rich strength in the Potentiometers - 3329 Single Turn DIP/RoHS field. We implement lean production workshop management system, create an green environment, improve quality, and shape corporate image. We create advanced business process with high work efficiency through the scientific management mode and the complete internal office system.
