3266 Trimming Potentiometer

Resistance Tolerance: ±10%
Terminal Resitance: ≤3%Or 3Ω
Contact Resistance Vartion: ≤3%Or 3Ω
Insulation Resistance: R1≥1GΩ

Send Inquiry

Product Introduction

Product Description

This kind of 3266 Trimming Potentiometer is used where it is necessary to adjust the circuit current or to change the resistance of the circuit. It has three terminals, two of which are fixed and one sliding contact, which can change the resistance between the sliding end and the two fixed ends via sliding. In addition, the 3266 Trimming Potentiometer has the advantages of high quality, compact structure, sophisticated design, long using life, low failure rate, stable operation as well as high cost effective. It is widely applied in digital products, home appliances, etc. It wins a good reputation among customers due to excellent performance. Besides, we offer products with various specifications to meet the requests of different clients.

Features

Resistance Tolerance: ±10%<br />

Terminal Resitance: ≤3%Or 3Ω<br />

Contact Resistance Vartion: ≤3%Or 3Ω<br />

Insulation Resistance: R1≥1GΩ<br />

Specification

Range Of Nominal Resistance	10Ω-2MΩ
Resistance Tolerance	±10%
Terminal Resitance	≤3%Or 3Ω
Contact Resistance Vartion	≤3%Or 3Ω
Insulation Resistance	R1≥1GΩ
Withstand Voltage	101.2kpa 500v 8 5kpa 350v
Effective Electrical Travel	≥Total mechanical travel 70%

Rated Power	+70°C 0.5W； +125°C 0W
Temperature Range	-55°C- + 125°C
Tcr	±250、±100ppm/°C
5 Cycle	△ R≤±2%R, △(Uab/Uac)≤±5%
Collision	390m/s2. 4000times AR≤ ±3%R
Vibration 10~500HZ,0.75mm Or 98m/S2, 6h	△R≤ ±1%R ，△（Uab/Uac) ≤±2%
Climatic Order	△R≤±3%R, R1≥100MΩ
7ctceiectrical Endurance	0.5W、1000h、△R≤±3%R
Mechanical Endurance	200cycles、△R≤±3%R
Steady Damp Heat	△R≤±3%R、R1≥100MΩ

Total Mechanical Travel	280°
Staring Torque	<20mN.m
Stopping Torque	>50mN.m
Standard Package	50pcs/tube
